How Should Roof Drawings Be Reconciled With a PV Site Survey

Use a discrepancy register before the layout is frozen. Compare the drawing revision, measured geometry and current roof equipment, then assign each difference to a reviewer. An old drawing can describe the original building without representing later changes. Record uncertainty explicitly rather than silently adjusting a supplier layout.

Concept illustration for how should roof drawings be reconciled with a pv site survey.

Concept illustration • X-SOLAR • 屋顶图纸与光伏现场勘查不一致时如何处理

Practical review checklist

· Identify the baseline. Record the drawing number, date, scale and responsible author before using it for a proposal.

· Map the differences. Mark added vents, altered roof areas and missing dimensions on a separate review copy. Keep the source drawing unchanged.

· Trace the evidence. Attach dated photographs and survey notes to each item so the engineer can identify how it was found.

· Close each item. Record the checked dimension, reviewer and resulting layout revision. Keep unresolved areas outside the approved layout.

When to request clarification

Pause the affected layout when there is no reliable basis for dimensions or the structural record conflicts with observed alterations. A visual check of roof cladding does not confirm the supporting structure.

Questions buyers ask

Can a satellite image settle a drawing conflict? It can identify a question, but checked site information is needed to resolve it.

What should be recorded when information is missing? Record the missing evidence, responsible reviewer and condition that must be resolved before the affected decision.

Information to send with an enquiry

Send drawing revisions, a marked discrepancy plan, survey dates and the decisions needed from the structural or roof reviewer.

This is a project discussion checklist, not an installation instruction or an approval. The selected manufacturers, project engineer and local authority must confirm the applicable requirements.

Related X-SOLAR guide: Roof engineering assessment checklist

Further reading: Australian Government Solar Consumer Guide — design considerations

屋顶图纸与光伏现场勘查不一致时如何处理

在布局定稿前建立差异表，对照图纸版本、实测几何和当前设备。旧图纸可能准确记录原建筑，却不包含后期改造；应逐项明确差异、责任人和待确认状态。

实用核对清单

· 确认基准：记录图号、日期、比例和编制单位，再作为方案依据。

· 标记差异：在审阅副本标出新增设备、屋面变化和缺失尺寸，保留源图。

· 追溯证据：每个问题关联带日期照片和测量记录。

· 逐项关闭：记录复核尺寸、审阅人及布局版本，未解决区域不纳入确认布局。

需要澄清的情况

尺寸无可靠依据或结构资料与改造现状矛盾时，暂停相关区域布局；仅观察面层不能确认支承结构。
