What Roof Survey Photos Should a Flexible PV Supplier Receive

A useful photo set connects every close-up to a marked roof plan. Send overall views, roof build-up and condition details, obstructions, drainage and accessible fixing interfaces. Photos help a flexible PV supplier identify questions; they do not establish roof capacity, material compatibility or permission to install. Record the survey date and what could not be inspected.

Concept illustration of an industrial roof, a camera and an indexed roof survey photo set.

Concept illustration • X-SOLAR • 柔性光伏询盘需要哪些屋面勘查照片

Practical review checklist

· Create a location key. Number roof zones on a plan and use the same identifiers in filenames. Include orientation and the camera viewpoint so another reviewer can place each detail.

· Show the existing condition. Photograph seams, laps, coatings, visible corrosion, previous repairs and any observed ponding. Describe observations without diagnosing hidden layers from appearance.

· Capture the interfaces. Show skylights, vents, roof edges, drains, cable entries and existing equipment. Record approximate context for discussion, but obtain checked dimensions before layout decisions.

· Record access limits. Identify areas seen only from the ground or through records. Use competent survey personnel and an agreed safe access plan; do not climb onto an unassessed roof to complete the file set.

When to request clarification

Request a follow-up survey when photographs and drawings disagree, the substrate is unidentified or critical interfaces are hidden. Treat the proposal as conditional until the missing evidence is supplied. A clear photo cannot replace a roof section or written installation limits.

Questions buyers ask

Can aerial images replace close-ups? They are useful for overall context, but may not show coatings, seams or condition adequately.

Should photos include measurements? Include a reliable reference where safely obtainable, and distinguish checked dimensions from estimates.

Information to send with an enquiry

Send a dated, indexed photo folder; the corresponding roof plan; known roof material and repair history; the proposed module model; and the specific questions requiring a supplier or engineer response. Remove unrelated personal or security-sensitive details.

This is a project discussion checklist, not an installation instruction or an approval. The selected manufacturers, project engineer and local authority must confirm the applicable requirements.

Related X-SOLAR guide: Roof engineering assessment checklist

Further reading: Australian Government Solar Consumer Guide — design considerations

柔性光伏询盘需要哪些屋面勘查照片

有效的屋面照片应能通过编号定位到屋顶图纸。提供整体视角、材料与现状细节、障碍物、排水及可见固定接口，并注明拍摄日期和未能检查的区域。照片用于提出技术问题，不能直接证明承载能力、材料兼容性或安装许可。

实用核对清单

· 建立定位索引：图纸分区、照片文件名和拍摄方向保持一致，让审阅者能找到每个细节的位置。

· 记录当前状态：拍摄接缝、涂层、可见腐蚀、旧修补和观察到的积水；不要仅凭外观推断隐藏构造。

· 展示关键接口：包括天窗、通风设备、屋边、排水口、线缆入口和既有设备；布局所需尺寸须另行核实。

· 注明勘查限制：标记仅从地面或历史资料观察的区域，由具备能力的人员按已确认的安全进入方案勘查。

需要澄清的情况

照片与图纸矛盾、基材不明或关键接口被遮挡时，应追加勘查并保留条件项。清晰照片仍不能替代屋面剖面资料和型号安装边界。

常见问题
