What Belongs in a Rooftop PV Obstruction Register

List every feature that can affect the usable layout, access or a building service. A roof area measurement alone does not capture skylights, vents, ducts and equipment service space. Give each obstruction an identifier and distinguish measured information from provisional estimates before a flexible PV arrangement is proposed.

Concept illustration for what belongs in a rooftop pv obstruction register.

Concept illustration • X-SOLAR • 屋顶光伏障碍物清单应包含什么

Practical review checklist

· Locate each feature. Link the roof plan position to a photograph and a short description of the equipment or opening.

· Record geometry. Provide checked footprint and height information for review, and mark measurements that are still approximate.

· Identify the owner. Ask who operates the feature and what service access, ventilation or replacement space it requires.

· Update the layout. Keep reserved areas visible on each revision and record changes introduced by other building contractors.

When to request clarification

Request clarification when an object is unlabelled or its maintenance envelope is unknown. Do not replace the equipment owner's requirements with a generic clearance drawn from another project.

Questions buyers ask

Is the visible footprint the whole reserved area? No. Service access and equipment replacement can require additional project-specific space.

What should be recorded when information is missing? Record the missing evidence, responsible reviewer and condition that must be resolved before the affected decision.

Information to send with an enquiry

Send the indexed roof plan, checked obstacle geometry, service-owner requirements and any planned equipment changes.

This is a project discussion checklist, not an installation instruction or an approval. The selected manufacturers, project engineer and local authority must confirm the applicable requirements.

Related X-SOLAR guide: Roof engineering assessment checklist

Further reading: Australian Government Solar Consumer Guide — design considerations

屋顶光伏障碍物清单应包含什么

障碍物清单应覆盖影响布局、可达性和建筑服务的设施。屋顶总面积无法反映天窗、通风口、管道及设备检修空间，应编号并区分实测与暂估资料。

实用核对清单

· 逐项定位：将平面图位置与照片、设施说明关联。

· 记录几何：提交核实的占地与高度，明确尚为估算的数据。

· 识别责任人：确认设施使用方及检修、通风、更换需求。

· 更新布局：持续显示预留区，并记录其他施工方新增设施。

需要澄清的情况

设施身份或检修空间不明时须澄清，不套用其他项目的通用间距。
